Page #7 background imageLoading...
Page #7 background image
Service and
support
Optional service upgrades (country-specific) are available through Lenovo Services offerings:
8-hour or 4-hour response time, warranty extension up to 5 years, Priority Technical Support,
and Keep Your Drive Multi-Drive.
Dimensions Height: 375 mm (14.8 in.), width: 175 mm (6.9 in.), depth: 431 mm (17.0 in.)
Weight Maximum: 12.5 kg (27.6 lb)
Components Specification
Relationship models
TS150 relationship models are country-specific; that is, each country may define their own server models,
and not all server models are available in every country.
For a list of the TS150 relationship models (Machine Types 70LU and 70LW), contact a Lenovo or Lenovo
Business Partner representative in your country.
The TS150 server models are shipped with the following items:
Electronic Publications Flyer
ThinkServer EasyStartup Quick Start Guide printed publication
One country-specific power cord (except EMEA)
TopSeller models
TS150 TopSeller models are country-specific; that is, each country may define their own server models, and
not all server models are available in every country.
For a list of the TS150 TopSeller models (Machine Types 70LV and 70LX), contact a Lenovo or Lenovo
Business Partner representative in your country, or refer to the TS150 PSREF page:
http://psref.lenovo.com/Product/ThinkServer_TS150
The TS150 server models are shipped with the following items:
Electronic Publications Flyer
ThinkServer EasyStartup Quick Start Guide printed publication
One country-specific power cord (except EMEA)
Processors
Lenovo ThinkServer TS150 (Intel Xeon E3-1200 v5, Core i3, Pentium/Celeron G Series Processors) 7

Other manuals for Lenovo ThinkServer TS150

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lenovo ThinkServer TS150 and is the answer not in the manual?

Lenovo ThinkServer TS150 Specifications

General IconGeneral
Bus typeDMI3
Scalability1S
Processor cache8 MB
Processor cores4
Processor modelE3-1225V5
System bus rate8 GT/s
Processor seriesIntel Xeon E3-1200 v5
Processor socketLGA 1151 (Socket H4)
Processor codenameSkylake
Execute Disable BitYes
Processor frequency3.3 GHz
Processor cache typeSmart Cache
Processor lithography14 nm
Processor manufacturerIntel
Processor package size37.5 x 37.5 mm
Processor boost frequency3.7 GHz
Processor operating modes64-bit
PCI Express configurations1x16, 1x8+2x4, 2x8
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)80 W
Number of processors installed1
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor1.35 V
Memory channels supported by processorDual
Memory clock speeds supported by processor1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
Maximum internal memory supported by processor64 GB
HDD size3.5 \
RAID levels0, 1, 5, 10
HDD interfaceSerial ATA
Optical drive typeDVD-ROM
Total storage capacity2000 GB
Maximum storage capacity24 TB
Number of HDDs installed2
Internal memory8 GB
Memory clock speed2133 MHz
Internal memory typeDDR4-SDRAM
Memory layout (slots x size)1 x 8 GB
On-board graphics card ID0x191D
On-board graphics card modelIntel® HD Graphics P530
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.7 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency400 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)1150 MHz
Number of displays supported (on-board graphics)3
Cabling technology10/100/1000Base-T(X)
Ethernet interface typeGigabit Ethernet
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity8
PCI Express slots version3.0
Operating altitude0 - 3048 m
Storage temperature (T-T)-40 - 60 °C
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)8 - 80 %
Power supply400 W
Power supply input frequency50 - 60 Hz
Redundant power supply (RPS) support-
Chassis typeTower
Operating system installedWindows Server 2012 Foundation
Compatible operating systemsWindows Server 2012/2012 R2, Red Hat Enterprise Linux, SUSE Linux 11/12, Windows 10, Canonical Ubuntu 14.04, VMware vSphere 2015
Processor ARK ID88168
Intel Secure Key Technology version1.00
Intel® Hyper Threading Technology (Intel® HT Technology)No
Weight and Dimensions IconWeight and Dimensions
Depth431 mm
Width175 mm
Height375 mm
Weight12500 g
