Lenovo ThinkServer TS150 Product Guide

Drive bays 4x 3.5-inch + 1x 2.5-inch non-hot-swap SATA drive bays. Optional 2x SD card slots.
Drive types 2.5-inch drives (in a 3.5-inch drive tray):
SATA SSDs up to 960 GB
3.5-inch drives:
SATA HDDs up to 2 TB
Nearline (NL) SATA HDDs up to 6 TB
SD cards up to 8 GB.
Intermix of SATA HDDs and SSDs is supported within a system, but not within a RAID
array.
Storage capacity Up to 24 TB with 4x 6 TB 3.5-inch NL SATA HDDs
Up to 8 TB with 4x 2 TB 3.5-inch SATA HDDs
Up to 4.8 TB with 5x 960 GB 2.5-inch SATA SSDs
RAID support Non-RAID with the integrated SATA controller.
RAID 0, 1, 10, and 5 with ThinkServer RAID 121i.
RAID 0, 1, 10 with ThinkServer RAID 520i. Optional RAID 5, 50 upgrade.
Optical drive bays Two without a backup drive or one with a backup drive. Support for DVD-ROM or DVD-RW.
Backup drive bays One. Support for the optional RDX backup drive.
Network interfaces One integrated Gigabit Ethernet (10/100/1000 Mbps) RJ-45 port (Intel I219LM): A
shared port
for management and data.
I/O expansion slots Slot 1: PCIe 3.0 x16 (x16-wired); full-height, half-length
Slot 2: PCIe 3.0 x1 (x1-wired); full-height, half-length
Slot 3: PCIe 3.0 x16 (x4-wired); full-height, half-length
Slot 4: PCIe 3.0 x1 (x1-wired); full-height, half-length
Ports Front: 2x USB 3.0 ports.
Rear: 6x USB 3.0 ports, 1x DisplayPort port, 1x DB-15 VGA port, 1x DB-9 serial port,
3x audio connectors (line-in, line-out, microphone).
Internal: 1x USB 2.0 port for the RDX backup drive.
Cooling Three fixed system fans with Intelligent Cooling Engine (ICE).
Power supply One fixed 250 W AC (100 - 240 V) power supply (80 PLUS Bronze) or one fixed 400 W AC (100
- 240 V) power supply (80 PLUS Platinum).
Hot-swap parts None.
Systems
management
UEFI, system LEDs, ThinkServer EasyStartup, ThinkServer EasyUpdate, ThinkServer Power
Planner, and ThinkServer Diagnostics, Intel Active Management Technology (AMT) 11.
Security features Power-on password, administrator's password, Intrusion switch (select models), Trusted
Cryptographic Module (TCM) (optional), security lock slot, and padlock loop.
Video Intel HD Graphics integrated into a processor (select models).
NVS 315 Graphic Adapter by NVIDIA (select models).
Quadro K620 Graphic Adapter by NVIDIA (select models)
Maximum resolution is 1920x1200 at 60 Hz with 32 bits per pixel (16M colors).
Operating systems Microsoft Windows 10; Microsoft Windows Server 2012, 2012 R2, and 2016; Red Hat
Enterprise Linux (RHEL) Server 6 and 7; SUSE Linux Enterprise Server (SLES) 11 and 12;
VMware vSphere (ESXi) 5.5, 6.0, and 6.5.
Warranty One-year or three-year (model dependent) customer-replaceable unit (CRU) and on-site
limited warranty with 9x5 next business day (NBD).
Components Specification
Lenovo ThinkServer TS150 (Intel Xeon E3-1200 v5, Core i3, Pentium/Celeron G Series Processors) 6

Lenovo ThinkServer TS150 Specifications

General

Bus type	DMI3
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E3-1225V5
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Execute Disable Bit	Yes
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
HDD size	3.5 \
RAID levels	0, 1, 5, 10
HDD interface	Serial ATA
Optical drive type	DVD-ROM
Total storage capacity	2000 GB
Maximum storage capacity	24 TB
Number of HDDs installed	2
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 8 GB
On-board graphics card ID	0x191D
On-board graphics card model	Intel® HD Graphics P530
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
PCI Express slots version	3.0
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	8 - 80 %
Power supply	400 W
Power supply input frequency	50 - 60 Hz
Redundant power supply (RPS) support	-
Chassis type	Tower
Operating system installed	Windows Server 2012 Foundation
Compatible operating systems	Windows Server 2012/2012 R2, Red Hat Enterprise Linux, SUSE Linux 11/12, Windows 10, Canonical Ubuntu 14.04, VMware vSphere 2015
Processor ARK ID	88168
Intel Secure Key Technology version	1.00
Intel® Hyper Threading Technology (Intel® HT Technology)	No

Weight and Dimensions

Depth	431 mm
Width	175 mm
Height	375 mm
Weight	12500 g
