Lenovo ThinkServer TS150 Product Guide

Controllers for internal storage
The following table lists the internal RAID controllers and the additional options that are used for the internal
disk storage of the TS150 server.
Table 6. Controllers for internal storage
Description Part number
Maximum
supported
ThinkServer RAID 121i Controller None# 1
ThinkServer RAID 520i PCIe Adapter 4XC0G88840 1
ThinkServer RAID 520i RAID 5 Upgrade 4XC0G88841 1
# RAID 121i is an onboard hardware-assist RAID controller.
The RAID 121i is an onboard RAID controller that does not consume a PCIe slot. The RAID 520i adapter
is supported only in the PCIe slot 3.
Important: The RAID 121i controller is not supported by virtualization hypervisors, including VMware
vSphere (ESXi), Linux KVM, Xen, and Microsoft Hyper-V.
The following table summarizes features of supported internal storage controllers.
Table 7. Internal storage controller features and specifications summary
Feature RAID 121i RAID 520i
Part number None 4XC0G88840
Form factor Onboard Low profile
Controller chip Not applicable* LSI SAS3008
Host interface Not applicable* PCIe 3.0 x8
Port interface 6 Gbps SATA 12 Gbps SAS
Number of internal drive ports 6** 8
Internal port connectors 6x L-shape SATA 2x Mini-SAS HD x4 (SFF-8643)
Drive interface SATA SAS, SATA
Drive type HDD, SSD HDD, SSD
Non-hot-swap drive support Yes Yes
Hot-swap drive support Yes Yes
Optical drive support Yes No
Maximum number of drives 6** 8
RAID levels 0/1/10/5 0/1/10, Optional 5/50 (4XC0G88841)
JBOD mode Yes Yes
Cache None None
Cache protection None None
FastPath None None
CacheCade Pro 2.0 None None
* The RAID 121i is a hardware-assist, software RAID feature (Intel Rapid Storage Technology Enterprise [RSTe]) integrated into
the Intel C236 Platform Controller Hub (PCH).
** Up to four ports are used for SATA HDDs or SSDs, and the remaining two ports are used for optical drives; or up to five ports
are used for SATA HDDs or SSDs, and the remaining port is used for an optical drive.
Lenovo ThinkServer TS150 (Intel Xeon E3-1200 v5, Core i3, Pentium/Celeron G Series Processors) 11

Lenovo ThinkServer TS150 Specifications

General

Bus type	DMI3
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E3-1225V5
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Execute Disable Bit	Yes
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
HDD size	3.5 \
RAID levels	0, 1, 5, 10
HDD interface	Serial ATA
Optical drive type	DVD-ROM
Total storage capacity	2000 GB
Maximum storage capacity	24 TB
Number of HDDs installed	2
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 8 GB
On-board graphics card ID	0x191D
On-board graphics card model	Intel® HD Graphics P530
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
PCI Express slots version	3.0
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	8 - 80 %
Power supply	400 W
Power supply input frequency	50 - 60 Hz
Redundant power supply (RPS) support	-
Chassis type	Tower
Operating system installed	Windows Server 2012 Foundation
Compatible operating systems	Windows Server 2012/2012 R2, Red Hat Enterprise Linux, SUSE Linux 11/12, Windows 10, Canonical Ubuntu 14.04, VMware vSphere 2015
Processor ARK ID	88168
Intel Secure Key Technology version	1.00
Intel® Hyper Threading Technology (Intel® HT Technology)	No

Weight and Dimensions

Depth	431 mm
Width	175 mm
Height	375 mm
Weight	12500 g
