Lenovo ThinkServer TS150 Product Guide

I/O expansion
The TS150 server has four I/O expansion slots:
Slot 1: PCIe 3.0 x16 (x16-wired); full-height, half-length
Slot 2: PCIe 3.0 x1 (x1-wired); full-height, half-length
Slot 3: PCIe 3.0 x16 (x4-wired); full-height, half-length
Slot 4: PCIe 3.0 x1 (x1-wired); full-height, half-length
The following adapter types are supported:
RAID adapters (Refer to the Controllers for internal storage)
Network adapters (Refer to the Network adapters section)
Network adapters
The TS150 server has one integrated Gigabit Ethernet port that is based on the Intel I219LM NIC (a shared
port for operating system access and management network).
The onboard NIC has the following features:
1 Gb Ethernet IEEE 802.3, 802.3u, and 802.3ab PHY specifications compliant
Integrated PHY for 10/100/1000 Mbps with speed and duplex auto-negotiation
Energy Efficient Ethernet (IEEE 802.3az)
Wake on LAN
VLAN tagging (IEEE 802.1Q)
Class of Service (CoS) priority (IEEE 802.1p) marking
TCP/UDP checksum and segmentation offload (IPv4 and IPv6)
Receive Side Scaling
Jumbo Frames (up to 9K)
Timing and Synchronization (IEEE 802.1as / IEEE 1588)
Load balancing and failover teaming support:
Adapter fault tolerance (AFT)
Switch fault tolerance (SFT)
Adaptive load balancing (ALB)
The following table lists the network adapter options for the TS150 server.
Table 12. Network adapter options
Description Part number
Maximum
supported
ThinkServer I210-T1 PCIe 1Gb 1-Port Base-T Ethernet Adapter by Intel (1x RJ-45 port) 4XC0G88844 2
ThinkServer I350-T2 PCIe 1Gb 2 Port Base-T Ethernet Adapter by Intel (2x RJ-45 ports) 4XC0F28730 2
ThinkServer I350-T4 PCIe 1Gb 4 Port Base-T Ethernet Adapter by Intel (4x RJ-45 ports) 4XC0F28731 2
ThinkServer TS150 PCIe Wireless Card 4XC0G88846 1*
* Available only in China.
GPU adapters
Lenovo ThinkServer TS150 (Intel Xeon E3-1200 v5, Core i3, Pentium/Celeron G Series Processors) 14

Lenovo ThinkServer TS150 Specifications

General

Bus type	DMI3
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E3-1225V5
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Execute Disable Bit	Yes
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
HDD size	3.5 \
RAID levels	0, 1, 5, 10
HDD interface	Serial ATA
Optical drive type	DVD-ROM
Total storage capacity	2000 GB
Maximum storage capacity	24 TB
Number of HDDs installed	2
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 8 GB
On-board graphics card ID	0x191D
On-board graphics card model	Intel® HD Graphics P530
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
PCI Express slots version	3.0
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	8 - 80 %
Power supply	400 W
Power supply input frequency	50 - 60 Hz
Redundant power supply (RPS) support	-
Chassis type	Tower
Operating system installed	Windows Server 2012 Foundation
Compatible operating systems	Windows Server 2012/2012 R2, Red Hat Enterprise Linux, SUSE Linux 11/12, Windows 10, Canonical Ubuntu 14.04, VMware vSphere 2015
Processor ARK ID	88168
Intel Secure Key Technology version	1.00
Intel® Hyper Threading Technology (Intel® HT Technology)	No

Weight and Dimensions

Depth	431 mm
Width	175 mm
Height	375 mm
Weight	12500 g
