Lenovo ThinkServer TS150 Product Guide

Key features
The ThinkServer TS150 server is an office-friendly tower server that has been optimized to provide
enterprise-class features to small-to-medium-sized businesses, retail stores, and distributed enterprises.
Scalability and performance
The TS150 offers numerous features to boost performance, improve scalability, and reduce costs:
The Intel Xeon processor E3-1200 v5 improves productivity by offering affordable single-socket
system performance with 4-core processors with up to 3.7 GHz core speeds and up to 8 MB cache.
Intelligent and adaptive system performance with Intel Turbo Boost Technology 2.0 allows processor
cores to run at maximum speeds during peak workloads by temporarily going beyond processor
thermal design power (TDP).
Intel Hyper-Threading Technology boosts performance for multithreaded applications by enabling
simultaneous multithreading within each processor core, up to two threads per core.
Intel Virtualization Technology integrates hardware-level virtualization hooks that allow operating
system vendors to better use the hardware for virtualization workloads.
Up to four 2133 MHz DDR4 ECC or non-ECC UDIMMs provide speed and capacity of up to 64 GB.
The server offers PCI Express 3.0 I/O expansion capabilities that increase the theoretical maximum
bandwidth by almost 100% (8 GTps per link using 128b/130b encoding) compared to the PCI
Express 2.0 (5 GTps per link using 8b/10b encoding).
With Intel Integrated I/O Technology, the PCI Express 3.0 controller is integrated into the Intel Xeon
processor E3-1200 v5 product family. Such integration reduces I/O latency and increases overall
system performance.
Up to five non-hot-swap (NHS) drive bays provide flexible internal storage capacity.
The use of solid-state drives (SSDs) instead of, or along with, traditional spinning drives (hard disk
drives or HDDs) can significantly improve I/O performance.
Availability and serviceability
The TS150 provides many features to simplify serviceability and increase system uptime:
The TS150 supports UDIMM memory with ECC protection which provides error correction not
available in PC-class "servers" that use parity memory. Avoiding system crashes (and data loss) due
to soft memory errors means greater system uptime.
Tool-less cover removal provides easy access to upgrades and serviceable parts, such as memory
and adapter cards.
A choice of affordable onboard SATA RAID or advanced hardware RAID redundancy offers data
protection and greater system uptime.
The use of SSDs can provide better reliability than the use of traditional HDDs, for greater uptime.
Built-in Active Management Technology continuously monitors system parameters, sends alerts, and
enables administrators to perform remote recovery actions to minimize downtime.
The ThinkServer EasyUpdate firmware update tool enables you to keep your server firmware up-to-
date and helps you avoid unnecessary server outages.
The ThinkServer Diagnostics software speeds up troubleshooting tasks to reduce service time.
One-year or three-year customer-replaceable unit (CRU) and onsite limited warranty with next
business day response. Optional service upgrades are available.
Lenovo ThinkServer TS150 (Intel Xeon E3-1200 v5, Core i3, Pentium/Celeron G Series Processors) 2

Lenovo ThinkServer TS150 Specifications

General

Bus type	DMI3
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E3-1225V5
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Execute Disable Bit	Yes
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
HDD size	3.5 \
RAID levels	0, 1, 5, 10
HDD interface	Serial ATA
Optical drive type	DVD-ROM
Total storage capacity	2000 GB
Maximum storage capacity	24 TB
Number of HDDs installed	2
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 8 GB
On-board graphics card ID	0x191D
On-board graphics card model	Intel® HD Graphics P530
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
PCI Express slots version	3.0
Operating altitude	0 - 3048 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	8 - 80 %
Power supply	400 W
Power supply input frequency	50 - 60 Hz
Redundant power supply (RPS) support	-
Chassis type	Tower
Operating system installed	Windows Server 2012 Foundation
Compatible operating systems	Windows Server 2012/2012 R2, Red Hat Enterprise Linux, SUSE Linux 11/12, Windows 10, Canonical Ubuntu 14.04, VMware vSphere 2015
Processor ARK ID	88168
Intel Secure Key Technology version	1.00
Intel® Hyper Threading Technology (Intel® HT Technology)	No

Weight and Dimensions

Depth	431 mm
Width	175 mm
Height	375 mm
Weight	12500 g
