Table 128. Memory sparing with six processors (Processors 3 and 4, 26 to 48 total DIMMs installed in server)
Total Processor 3 Processor 4 Total
DIMMs 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 DIMMs
26
5 6 7 8 17 18 19 20 26
28
5 6 7 8 17 18 19 20 28
30
5 6 7 8 9 10 17 18 19 20 30
32 5 6 7 8 9 10 17 18 19 20 21 22 32
34 5 6 7 8 9 10 17 18 19 20 21 22 34
36 5 6 7 8 9 10 17 18 19 20 21 22 36
38
5 6 7 8 9 10 17 18 19 20 21 22 38
40
5 6 7 8 9 10 17 18 19 20 21 22 40
42 3 4 5 6 7 8 9 10 17 18 19 20 21 22 42
44 3 4 5 6 7 8 9 10 15 16 17 18 19 20 21 22 44
46 3 4 5 6 7 8 9 10 15 16 17 18 19 20 21 22 46
48 3 4 5 6 7 8 9 10 15 16 17 18 19 20 21 22 48
Related DIMM population sequences for six processor systems:
• Processor 3 and 4 DIMM population sequences:
– Table 127 “Memory sparing with six processors (Processors 3 and 4, 12 to 24 total DIMMs installed in
server)” on page 152
– Table 129 “Memory sparing with six processors (Processors 3 and 4, 50 to 72 total DIMMs installed in
server)” on page 154
• To continue populating DIMMs for a system with 26 to 48 DIMMs:
– Table 125 “Memory sparing with six processors (Processors 1 and 2, 26 to 48 total DIMMs installed in
server)” on page 150
– Table 131 “Memory sparing with six processors (Processors 5 and 6, 26 to 48 total DIMMs installed in
server)” on page 156
– Table 134 “Memory sparing with six processors (Processor 7 slot, which is actually Processor 6, 26 to
48 total DIMMs installed in server)” on page 159
Chapter 3. Server hardware setup 153
