Install an adapter
Adapters are in the I/O tray that is accessed from the rear of the server.
Install the LOM adapter (slot 9) and other adapters that are installed directly in the I/O tray (adapters 5 to 8)
before installing adapters that are in the I/O tray risers.
Installation considerations for the Mellanox Innova™-2 Flex Open Programmable SmartNIC
Review the following guidelines before installing the Mellanox Innova™-2 Flex Open Programmable
SmartNIC:
• If you install the Mellanox Innova™-2 Flex Open Programmable SmartNIC in the ThinkSystem SR950, the
maximum supported ambient temperature for the system is 35°C.
• The Mellanox Innova™-2 Flex Open Programmable SmartNIC is not supported in the following adapter
slots: 1, 5, and 10.
• When installing the Mellanox Innova™-2 Flex Open Programmable SmartNIC in a 4-socket configuration:
– A maximum of two of these adapters can be installed in the system.
– The Mellanox Innova™-2 Flex Open Programmable SmartNIC can be installed only in adapter slots 6,
7, or 17.
– The installation of two of these adapters in contiguous, sequential slots is not supported. For example,
you cannot install two adapters in slots 6 and 7.
• When installing the Mellanox Innova™-2 Flex Open Programmable SmartNIC in an 8-socket configuration:
– A maximum of four of these adapters can be installed in the system.
– The Mellanox Innova™-2 Flex Open Programmable SmartNIC can be installed only in adapter slots 2,
3, 4, 6, 7, 11, 12, 13, 14, 15, 16, or 17.
– The installation of two of these adapters in contiguous, sequential slots is not supported. For example,
you cannot install two adapters in slots 2 and 3.
Install a LOM adapter in slot 9
The LOM adapter in slot 9 is in the I/O tray that is accessed from the rear of the server. With the I/O tray
removed from the chassis, insert the adapter in the I/O tray.
S002
CAUTION:
The power-control button on the device and the power switch on the power supply do not turn off the
electrical current supplied to the device. The device also might have more than one power cord. To
remove all electrical current from the device, ensure that all power cords are disconnected from the
power source.
“
” on page 56 “ ” on page 254
CAUTION:
228
ThinkSystem SR950 Setup Guide
