Table 151. Memory sparing with eight processors (Processors 7 and 8, 74 to 96 total DIMMs installed in server)
Total Processor 7 Processor 8 Total
DIMMs 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 DIMMs
74 3 4 5 6 7 8 9 10 15 16 17 18 19 20 21 22 74
76 3 4 5 6 7 8 9 10 15 16 17 18 19 20 21 22 76
78 3 4 5 6 7 8 9 10 11 12 15 16 17 18 19 20 21 22 78
80 3 4 5 6 7 8 9 10 11 12 15 16 17 18 19 20 21 22 23 24 80
82 3 4 5 6 7 8 9 10 11 12 15 16 17 18 19 20 21 22 23 24 82
84 3 4 5 6 7 8 9 10 11 12 15 16 17 18 19 20 21 22 23 24 84
86 3 4 5 6 7 8 9 10 11 12 15 16 17 18 19 20 21 22 23 24 86
88 3 4 5 6 7 8 9 10 11 12 15 16 17 18 19 20 21 22 23 24 88
90 3 4 5 6 7 8 9 10 11 12 15 16 17 18 19 20 21 22 23 24 90
92 3 4 5 6 7 8 9 10 11 12 15 16 17 18 19 20 21 22 23 24 92
94 1 2 3 4 5 6 7 8 9 10 11 12 15 16 17 18 19 20 21 22 23 24 94
96 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 96
Related DIMM population sequences for eight processor systems:
• Processor 7 and 8 DIMM population sequences:
– Table 148 “Memory sparing with eight processors (Processors 7 and 8, 16 to 24 total DIMMs installed
in server)” on page 173
– Table 149 “Memory sparing with eight processors (Processors 7 and 8, 26 to 48 total DIMMs installed
in server)” on page 174
– Table 150 “Memory sparing with eight processors (Processors 7 and 8, 50 to 72 total DIMMs installed
in server)” on page 175
• To continue populating DIMMs for a system with 74 to 96 DIMMs:
– Table 139 “Memory sparing with eight processors (Processors 1 and 2, 74 to 96 total DIMMs installed
in server)” on page 164
– Table 143 “Memory sparing with eight processors (Processors 3 and 4, 74 to 96 total DIMMs installed
in server)” on page 168
– Table 147 “Memory sparing with eight processors (Processors 5 and 6, 74 to 96 total DIMMs installed
in server)” on page 172
DCPMM installation order
The server also supports Intel Optane DC persistent memory modules (DCPMMs). Use this information to
determine the correct installation order, depending on the configuration.
Notes:
• Before installing DCPMMs and DRAM DIMMs, refer to “DC Persistent Memory Module (DCPMM) setup”
on page 177 and make sure to meet all the requirements.
• To verify if the presently installed processors support DCPMMs, examine the four digits in the processor
description. Only the processor with description meeting both of the following requirements support
DCPMMs.
– The first digit is 5 or a larger number.
Note: The only exception to this rule is Intel Xeon Silver 4215, which also supports DCPMM.
– The second digit is 2.
176
ThinkSystem SR950 Setup Guide
