Table 144. Memory sparing with eight processors (Processors 5 and 6, 16 to 24 total DIMMs installed in server)
Total Processor 5 Processor 6 Total
DIMMs 1 2 3 4
5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 DIMMs
16 7 8 19 20 16
18 7 8 19 20 18
20
7 8 19 20 20
22
7 8 19 20 22
24
7 8 19 20 24
Related DIMM population sequences for eight processor systems:
• Processor 5 and 6 DIMM population sequences:
– Table 145 “Memory sparing with eight processors (Processors 5 and 6, 26 to 48 total DIMMs installed
in server)” on page 170
– Table 146 “Memory sparing with eight processors (Processors 5 and 6, 50 to 72 total DIMMs installed
in server)” on page 171
– Table 147 “Memory sparing with eight processors (Processors 5 and 6, 74 to 96 total DIMMs installed
in server)” on page 172
• To continue populating DIMMs for a system with 16 to 24 DIMMs:
– Table 136 “Memory sparing with eight processors (Processors 1 and 2, 16 to 24 total DIMMs installed
in server)” on page 161
– Table 140 “Memory sparing with eight processors (Processors 3 and 4, 16 to 24 total DIMMs installed
in server)” on page 165
– Table 148 “Memory sparing with eight processors (Processors 7 and 8, 16 to 24 total DIMMs installed
in server)” on page 173
Chapter 3. Server hardware setup 169
