5 Device settings
Before initializing the device, you should set the XpressNet address
as well as the point address range.
To effect these settings,
remove the upper part of
the housing.
To do so, slightly bend the
ears of the lower part of
the housing to the outside.
The upper part can now
be easily removed.
The circuit board of the LW150 features two DIP switches to effect the
settings:
1
2
