Lenz Digital Plus LW150 - 11 Help in Case of Malfunction

45
E
11 Help in case of malfunction
Malfunction
Cause
Correction
No function (green LED off)
No operating voltage or
XpressNet inactive
Check the wiring of the
XpressNet
Ensure that the power
supply of the XpressNet is
not overloaded (p. 44).
Points do not switch, but
indicator changes
Point address range set
incorrectly
Set the DIP switch for the
address range correctly
(p. 30).
Red LED flashes
Communication error
between command station
and LW150
Check the setting of the
XpressNet address
(p. 34) and restart the
system.
LEDs for indication of
setting do not shine
Poling or wiring error when
connecting the LEDs
Check the wiring and
polarity of the LEDs
(p. 41)
