Lenze 2102 - Page 45

Appendix
8-13
L _^ONMObk
Code Name Note
C0067
C0161
C0168
*
[1...8]
Fault memor y
(P93XX)
Fault abbreviations LECOM fault numbers
TRIP Warning Message
--- 0
OC1 11
OC2 12
OC5 15
OU 1020
L
U
1
0
3
0
LU 1030
LP1 -
OH 50
O
H
3
5
3
O
H
3
5
3
OH4 2054
OH7 2057
OH8 58 2058
O
H
8
5
8
2
0
5
8
CE0 61 2061
CE1 62 2062
CE2 63 2063
C
E
3
6
4
2
0
6
4
CE3 64 2064
U15 70
CCr 71
P
r
0
7
5
P
r
0
7
5
Pr1 72
Pr2 73
Pr3 77
P
r
3
7
7
Pr4 78
PEr 74
PI 79
S
d
2
8
2
2
0
8
2
Sd2 82 2082
Sd3 83 2083
Sd6 86 2086
E
E
r
9
1
2
0
9
1
1
0
9
1
E
E
r
9
1
2
0
9
1
1
0
9
1
P03 153 2153
P13 163
NMAX 200
H05 105
H07 107
H10 110
H11 111
The individual faults are described in the Operating Instructions of the controller.
LECOM format: VD
C0248
*
LECOM input
selection
(P2102)
0 0 t o 255
The parameter LECOM input selection ensures the compatibility with previous master-system drivers according to the LECOM-A/B
specification V1.0. This code is only fully used with 93XX, since this series uses t he so-called array parameters, i. e. a code
consists o f several parameters (e.g. C0039 = JOG with 15 values). Code C0248 determines t he array element t o be accessed. The
functionality of the input selection is simulated (before e.g. C0038).
This input is valid for all LECOM accesses; i.e. the access of a standard parameter with a LECOM input selection that is not 0
results in a fault because the addressed value does not exist.
The array element can be directly addressed via a LECOM-A/B driver as from specification V2.0. This parameter should therefore
not be used any longer.
C0248 is included in every LECOM code bank (see C0249).
The parameter value is always set to 0 when switching on.
LECOM format: VD
