Appendix
8-14
L
_^ONMObk
Code NoteName
C0249
*
LECOM code bank
(P2102)
Code bank Code number
0 0 to 255 (Factory setting)
1 250 to 505
2 500 to 755
3 750 to 1005
4 1000 to 1255
5 1250 to 1505
6 1500 to 1755
7 1750 to 2005
8 2000 to 2255
9 2250 to 2505
10 2500 to 2755
11 2750 to 3005
12 3000 to 3255
13 3250 to 3505
14 3500 to 3755
15 3750 to 4005
The LECOM code bank ensures the compatibility with the master-system drivers according to the LECOM-A/B specification V1.0.
The maximum code number is 255. Wit h the code bank, an offset of 250 is added to the code number.
The code bank addressing is not effective with extended code addressing (LECOM-A/B specification).
The parameter value is always set to 0 when switching on.
LECOM format: VD
C1810
*
SW labelling
(P2102)
33S2102I_xy000
Software labelling of the 2102IB fieldbus modules
x = main SW version y = SW subversion
LECOM format: VS
C1811
*
SW generation
(P2102)
Software generation of the 2102IB fieldbus module
LECOM format: VS
C1920 Start status
(P2102)
0QSP
1 Controller inhibit
LECOM format: VD
C1922 Monitoring selection
code
(P2102)
0Notactive
1 Controller inhibit
2 QSP (quick stop)
LECOM format: VD
C1921 Shortened response
time
(P2102)
0Notactive
1active
LECOM format: VD
C1923 Monitoring time
(P2102)
50 to 65535ms
LECOM format: VD
C1962 Extended code No. See fault table
