DeviceNet
12 Parameter setting
12-4
L
BA2175 EN 2.0
Vendor-specific class (class 100) (GET/SET)
Instance 1
yte
• Attribute 1: Parameter data
Request Response
1 Code Low Code Low
2 Code High Code High
3 Subcode Subcode
4 Reserve Status • Byte value = 0: No errors
• Byte v alue ≠ 0: Incorrect message
The byte value indicates the error number. Its meaning is explained in the table below.
5
Data_1 Low
Data_1 Low
..
Data_1 High
Data_1 High
..
Data_2 Low
Data_2 Low
Data_2 High
Data_2 High
.
.
.
.
.
.
.
.
Data_22 Low
Data_22 Low
Data_22 High
Data_22 High
The following table lists the explanations for the error numbers:
Error code (hex) Explanation
03 Invalid data type
04 Invalid subcode no.
05 Invalid code no.
07 No access during operation
08 No access because of operating mode
09 No access because parameters can only be read
0A No access authorisation
0B Data block too long
0C Collision with o ther value ranges
0D Quit value range
0E General value range error
2X Error in AIF interface
jFF General error
