DeviceNet
12 Parameter setting
12-5
L BA2175 EN 2.0
Vendor-specific class (class 101) (GET/SET)
Instance 1
• Attribute 1: Process data monitoring code (2 byte)
0: No response (default)
1: Controller inhibit
2: Quick stop
This setting is saved as non-volatile value in the EEPROM.
Vendor-specific class (class 102) (GET/SET)
Instance 1
• VSC attribute 1: Process data length (2 byte)
0: Default value according to EDS file
1: 2 byte
...
12: 24 byte
Note: When changing the process data length, the process data length in the master must be adapted under ”produced / consumed data size”.
