Configuration
7-21
48XX/49XXSHB0399
Code Possible settingsNameCode
InfoSelectionLenze
Name
C029¤ Automatic
adjustment
for C025
100% This applies to all configurations:
If an automatic adjustment is not possible,
the previous value will be maintained.
--ok-- will not be displayed.
C007 = -5-, -6-, -9-, -20-:
Automatic adjustment for analog inputs
-100 % {0.1 %} 100.0%
1.Inhibit controller.
2.Setsetpointattheterminalselected.
3.Enter the required values.
4.C027 displays the calculated gain
factor.
C025 = -2- and tacho at X1/3, X1/4 or
C025 = -5- and actual value from armature voltage
feedback:
n
act
adjustment
0 rpm {1rpm} 5000rpm
Adjustment during operation:
1.Display of actual speed.
2.Measure real speed with hand tacho.
3.Enter real speed.
4.Drive accelerates to this speed.
5.C027 displays the calculated gain
factor.
C025 = -10-, -11-:
Adjustment of the digital frequency inputs X5, X9
-100.0 % {0.1 %} 100.0%
Automatic adjustment only possible, if X5
or X9 are not selected as acutal speed
inputs:
1.Display of actual output value.
2.Enter required output value.
3.C027 displays the calculated gain
factor.
C025 = -12-:
Adjustment of the resolver
-100.0 % {0.1 %} 100.0%
Automatic adjustment is only possible, if
the resolver is not used as speed
feedback system:
1.Display of actual output value.
2.Enter required output value.
3.C027 displays the calculated gain
factor.
