Lenze 4800 - Pre-Assembled Lenze System Cable

Automation
13-10
48XX/49XXSHB0399
13.3 Pre-assembled Lenze system cable
13.3.1 Resolver connection cable
Design Length [m] Order designation
5 EWLR005GM
10 EWLR010GM
15 EWLR015GM
20 EWLR020GM
P
l
g
a
t
b
o
t
h
e
n
d
s
25 EWLR025GM
P
l
ug a
t
b
o
t
h
en
d
s
30 EWLR030GM
35 EWLR035GM
40 EWLR040GM
45 EWLR045GM
50 EWLR050GM
only with motor plug 10 EWL0028
only with plug X7 for controller 2.5 EWL0027
DC motor
Controller
9
1
4900Str094
FIG 13-8 Resolver connection cable
