Configuration
7-31
48XX/49XXSHB0399
Code Name
Possible settings
Lenze Selection Info
C145*¤ Input
selection:
Analog
signal
1 -1- Input terminals X1/1, X1/2
-2- Input terminals X1/3, X1/4
-3- Input terminal X1/6
-4- Input terminal X1/8
-5- Digital frequency input X5
-6- Digital frequency input X9
-7- Resolver
-8- Motor potentiometer output
-9- Output process controller
-10- Output arithmetic block 2 output 1
-11- Fixed setpoint output
-12- Output arithmetic block 2 output 2
-13- Output dead band element output 1
-14- Output dead band elemeent output 2
-15- Output DT1 element output 1
-16- Output DT1 element output 2
-17- Output absolute value generator output 1
-18- Output absolute value generator output 2
-19- Output limiting element 1 output 1
-20- Output limiting element 1 output 2
-21- Output PT1 element output 1
-22- Output PT1 element output 2
-23- Output arithmetic block 3 output 1
-24- Output arithmetic block 3 output 2
-25- Output addition block 1 output 1
-26- Output addition block 1 output 2
-27- Output addition block 2 output 1
-28- Output addition block 2 output 2
-29- n
act
from C382
-30- n
set
from C050
-31- Deviation at n-controller (xw)
-32- Deviation at process controller (xw)
-33- Ramp function generator output
-34- n-controller output
-35- Square-wave generator
-36- Deviation at angle controller
-37- RFG output of process controller setpoint
-38- RFG output of process controller evaluation
-39- AIF process controller setpoint
-40- Output limiting element 2 output 1
-41- Output limiting element 2 output 2
-42- Output comparator 1
-43- Output comparator 2
The functions set under C146 can be
assigned to the input sources under
C145. Double assignment is not possible.
The function selected last is always
assigned to the input.
C007 = -5-, -6-, -9-, -20-:
The priority for these inputs can be
determined under C147.
Change of C005 (configuration):
The freely selected assignments are
overwritten with a basic assignement that
depends on the configuration.
Assignments set before must be repeated.
