[C111*] Signal for
C110
-0- No signal
-1- Main set-value (C046), reference: n
max
-2- Input ramp function generator, reference: n
max
-3- Outut ramp function generator, reference: n
max
-4- Additional set-value (C049), reference: n
max
-5- n
set
at the n controller input (C050), reference:
n
max
In the armature setting range: 100 %
M
max
correspond to 100 % I
max
(C022,
C023)
The actual armature current value I
act
(C054) is normalised according to the
controller:
I
act
X4/62, X4/63 X8 Type
1
6
A
4
4
V
1
1
0
k
H
z
4
9
0
2
-6- n
act
(C051), reference: n
max
(X4/63)
-8- n
act
(C382), reference: n
max
(X8)
-20- n controller output, reference: M
max
-21- M
set
(C047), reference: M
max
-22- I
set
(C063), reference: I
max
(C022, C023),
(X4/62)
1
6
A
4
.
4
V
1
1
0
k
H
z
4
9
0
2
25A 4.7V 118kHz 4903
55A 4.8V 120kHz 4904
110A 4.9V 122kHz 4905
200A 6.4V 159kHz 4906
250A 4.4V 110kHz 4907
3
3
0
A
5
2
V
1
2
9
k
H
z
4
X
0
8
-23- I
act
(C054), reference: (see ’Info’)
-25- M
set
(C056), reference: M
max
-28- I¼t load, reference: 100%
-29- I
2
¼t load, reference: 100%
-30- V
A
(C052), reference: 1000 V
330
A
5.2
V
129
k
H
z
4
X
08
500A 5.8V 144kHz 4X09
700A 5.8V 144kHz 4X11
1000A 5.8V 146kHz 4X12
1200A 7.0V 175kHz 4X13
-35- Mains frequency, reference: 30Hz = 0V, 70Hz
= 10V
-40- Field current set-value, reference: max. rated
field current I
Fmax
-41- Actual field current, reference: I
Fmax
-60- Output motor potentiometer, reference: 100%
-61- Output process controller, reference: 100%
-62- Output arithmetic block 2, reference: 100%
-63- Digital frequency input X5, reference: 100%
-64- Digital frequency input X9, reference: 100%
-65- Resolver, reference: 100%
-66- Digital / analog conversion 1 (C272), reference:
100%
-67- Digital / analog conversion 2 (C273), reference:
100%
-68- Motor power, reference: 5 V = P
rated
-69- Motor torque, reference: 5 V = M
rated
-70- Output dead band element, reference: 100%
-71- Output DT1 element, reference: 100%
-72- Output absolute value generator, reference:
100%
-73- Output limitation element 1, reference: 100%
-74- Output PT1 element, reference: 100%
-75- Output arithmetic block 3, reference: 100%
-76- Output addition block 1, reference: 100%
-77- Output addition block 2, reference: 100%
