Configuration
7-63
48XX/49XXSHB0399
Configuration C005 = -12-, -13- (digital actual value encoder)
The phase controller is overlayed under the following conditions:
- QSP function active
-V
p
of the phase controller (C254) higher 0
The I component of the speed controller must not be switched off via terminal or
code because otherwise the drive cannot generate the required torque.
Configuration C005 = -10-, -11- (analog actual value controller)
The phase controller is usually not activated. If the value falls below the n
act
=0
threshold (C019), the I component of the speed controller will be switched off.
Otherwise the drive would add a torque to the engaged brake because of the offset
values always available in analog systems.
Configuration C005 = -5X-
The phase controller is always active (if C254 > 0). A digital phase set-value is
generated from the analog set-value. The drive operates phase controlled.
