Configuration
7-76
48XX/49XXSHB0399
Code Name
Possible settings
C
o
d
e
N
a
m
e
Lenze Selection Info
C260* Upper motor
potentiometer
limit
100% -100.0 % {0.1 %} +100.0 % C260 must be higher than C261!
C261* Lower motor
potentiometer
limit
0% -100.0 % {0.1 %} +100.0 % C261 must be smaller than C260!
C262* Motor
potentiometer
acceleration
time
10 s 1 s {1 s} 5000 s C262 is activated if the motor
potentiometer terminal is set to ”UP”
Ref.: Change from 0...100%
C263* Motor
potentiometer
deceleration
time
10 s 1 s {1 s} 5000 s C263 is activated if the motor
potentiometer terminal is set to ”DOWN”
Ref.: Change from 0...100%
C264*¤ Motor
potentiometer
deactivation
function
0 -0- No function, motor potentiometer is not
changed.
-1- Down to 0%, motor potentiometer output
runs with the corresponding acceleration or
deceleration time to 0%.
-2- Down to lowest limit, motor potentiometer
output runs with the corresponding
acceleration or deceleration time to the value
under C261.
-3- Jump to 0%, motor potentiometer output
immediately changes to 0%.
-4- Jump to the lowest level, motor potentiometer
immediately changes to the value indicated
under C261.
-5- Up to the highest level, motor potentiometer
output runs with the corresponding
acceleration or deceleration to the value
indicated under C260.
Function, which is executed when
deactivating the motor potentiometer
(terminal DEACTIVE is set).
C265*¤ Initialisation
function
Sample &
Hold
0 -0- Acceptance of the saved value S&H output
accepts the value which was set before
switching the mains.
-1- Lower limit, S&H output accepts the value of
C261.
Function which is executed when
switching on the mains.
C266* Motor
potentiometer:
Operation via
keypad
100 % {0.1 %} + 100 % Under C266 the motor potentiometer can
also be operated with Vand W
Display: Output value of the motor
potentiometer in % and exact control
program value.
C267*¤ Sample and
Hold function
0 -0- S&H for motor potentiometer output
-1- S&H für FAI signal
