Configuration
7-88
48XX/49XXSHB0399
Code Name
Possible settings
C
o
d
e
N
a
m
e
Lenze Selection Info
C580* Input 1,
Comparator 1
0% -100.0 % {0.1 %} +100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C581* Input 2,
Limit value
for
comparator 1
0% -100.0 % {0.1 %} +100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C582* Hysteresis for
lower
threshold
Comparator 1
0% 0 % {0.1 %} +100 % Lower threshold = C581 - C582,
reference: C581
C583*¤ Memory
function
Comparator 1
-0- Memory function not active
The output is reset when the value falls below
the lower threshold (C581 - C582)
-1- Memory function active
The output remains set after initial switch on.
C584*¤ Reset
function
Comparator 1
-0- Reset function not active
-1- Reset function active
The activation resets the output
C590* Input 1,
Comparator 2
0% -100.0 % {0.1 %} +100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C591* Input 2,
Limit value
for
comparator 2
0% -100.0 % {0.1 %} +100.0 %
-200 % {1 %} +200 %
If an analog signal source (C145/C146) is
assigned, the parameter will be displayed
only.
C592* Hysteresis for
lower
threshold
Comparator 2
0% 0 % {0.1 %} +100 % Lower threshold = C591 - C592,
reference: C591
C593*¤ Memory
function
Comparator 2
-0- Memory function not active
The output is reset when the value falls below
the lower threshold (C591 - C592)
-1- Memory function active
The output remains set after initial switch on.
C594*¤ Reset
function
Comparator 2
-0- Reset function not active
-1- Reset function active
The activation resets the output
