Configuration
7-98
48XX/49XXSHB0399
Changeover of the monitoring function with active TRIP
Even if a monitoring function has activated a TRIP, which is still active, it can be
changed to warning or message:
( The display changes to warning or message.
( The TRIP remains active!
( Acknowledge the TRIP after fault elimination:
- under C067 with SH + PRG or
- via terminal ”TRIP reset”
Basic settingsfor some monitoring functions at configuration changeover
The monitoring function for ’defective analog encoder (Sd1), resolver fault (Sd2),
encoder fault at X5 (Sd3) and encoder fault at X9 (Sd4) are preset when the
configuration is changed (C005). The setting depends on the configuration.
Configuration Sd1
Defective analog
encoder
Sd2
Resolver fault
Sd3
Encoder fault at X5
Sd4
Encoder fault at X9
C005 = -10- switched off switched off switched off switched off
C005 = -11- TRIP switched off switched off switched off
C005 = -12- switched off TRIP switched off switched off
C005 = -13- switched off switched off switched off TRIP
C005 = -40- switched off switched off switched off switched off
C005 = -41- TRIP switched off switched off switched off
C005 = -42- switched off TRIP switched off switched off
C005 = -43- switched off switched off switched off TRIP
C005 = -52- switched off TRIP switched off switched off
C005 = -53- switched off switched off TRIP switched off
C005 = -62- switched off TRIP switched off switched off
C005 = -63- switched off switched off TRIP switched off
C005 = -72- switched off TRIP switched off switched off
These monitoring functions can be changed subsequently.
Display priority when different fault types occur
1. TRIP (C067)
2. Warning (C066)
3. Message with pulse inhibit (C065)
(Pulse inhibit is also activated when a warning is active)
4. Message without pulse inhibit (C065)
Independently of the priority, all faults are displayed in the corresponding codes
and entered in the corresponding history buffer.
