Configuration
7-102
48XX/49XXSHB0399
Code Name
Possible settings
C
o
d
e
N
a
m
e
Lenze Selection Info
C085*¤ Thermal
motor time
constant
1.0
min
1.0 min {0.1 min} 100.0 min Required for ”I
2
¼
t monitoring” (motor
protection)
C088 Rated
motor
current
0 A {0.1A} 100 A
100 A {1A} 3600 A
Rated current depends on the controller:
0..87A (4902)
0..135A (4903)
0..270A (4904)
0..450A (4905)
0..720A (4906)
0..900A (4907)
0..1200A (4X08)
0..1800A (4X09)
0..2520A (4X11)
0..3600A (4X12)
See motor nameplate
C119*¤ Selection of
monitoring
function
-15- OC5
-16- OC6
-22- OUE
-31- LU1
-32- LU
-41- LF
-42- OF
-50- OH
-61- CE0
-70- U15
-80- SP
-81- Sd1
-82- Sd2
-83- Sd3
-84- Sd4
-85- Sd5
-91- EEr
-93- dEr
-94- ACI
-96- FCI
-153- P03
-163- P13
-69- CE9
I ¼t overload (controller protection)
I
2
¼t overload (motor protection)
Mains overvoltage
Phase fault
Mains undervoltage
Mains underfrequency f
Mains
< 47Hz
Mains overfrequency f
Mains
> 63Hz
Overtemperature heat sink
Communication error (automation
interface)
 15V failure
Wrong signal source polarity
Tacho short circuit/interruption
Opencircuitofresolver
Encoder fault at X5
Encoder fault at X9
Defective setpoint encoder
Ext. TRIP terminal
Motor blocked
Interruption of armature circuit
Interruption of field circuit
Following error
Angle overflow
Communication error (serial interface)
[C120*] Change of
monitoring
function
-0- TRIP
-1- Warning
-2- Message with pulse inhibit
-3- Message without pulse inhibit
-4- Switched-off
The important monitoring functions are set
according to the changes of the
configuration under C005.
