Selection aid
15-14
48XX/49XXSHB0399
Parameter setting
Code Input Description
Input according to motor nameplate
C083 xxx A Rated field current
C084 xxx ms Armature-time constant
C088 xxx A Rated motor current
C090 xxx V Rated motor voltage
Input of current limits
C022, C023 xxx A Maximum motor current
Enter controller configuration
C000 -2- Extended code set
C005 -52- Speed control with phase controller
Adjustment of speed controller
C070 V
pn
At high inertias, adapt n - controller gain
Adjustment of the phase controller
C254 V
pw
Adapt V
pw
to the system, if V
pw
= 0, the phase controller is not
activated.
Application parameters
C011 xxx rpm Enter max. speed (this speed corresponds to v
max
)
C019 xxx rpm Set threshold n
act
=0
C240 xxx % n
max
Setting of the permissible speed deviation
C116 -5- Input selection of the digital output A5
C128 xxx s Time, during which the drive can leave the selected range, without a
message being sent
C255 xxxx incr Following error limit
C105 xxx s Deceleration time t
f
=2
:
s/v
pos
C116 -1- Input selection of the digital output A1
C117 -15- I
act
>I
x
C244 xxx % I
max
(limit value for the starting torque against the brake)
C038 -1- Input selection JOG 1
C039 xxx % C011 (save speed for v
pos
in JOG 1)
C038 -x- Input selection JOG x
C039 xxx % C011 (other speeds)
Save parameter
C003 Save parameter set
