Configuration
7-7
48XX/49XXSHB0399
Code Name
Possible settings
Lenze Selection Info
C100*¤ Input:
Additional
acceleration/
deceleration
times for
main
set-value
-1- Acceleration time T
ir1
/deceleration time T
if1
-2- Acceleration time T
ir2
/deceleration time T
if2
...
-15- Acceleration time T
ir15
/deceleration time T
if15
Extends T
ir
(C012) and T
if
(C013) by max.
15 value pairs. Can be changed under
C130:
1.Select additional times under C100.
2.Set C101 (T
ir
) or C103 (T
if
).
C101* Acceleration
time for
C100
0.00s 0s {0.01s} 1s
1 s {0.1s} 10s
10 s {1 s} 100 s
100 s {10 s} 990 s
Time refers to speed change 0...n
max
C103* Deceleration
time for
C100
0.00s 0s {0.01s} 1s
1 s {0.1s} 10s
10 s {1 s} 100 s
100 s {10 s} 990 s
Time refers to speed change 0...n
max
Assignment of the digital inputs
The of inputs to be assigned with the function ”enable additional acceleration and
deceleration times”, depends on the number of additional T
i
times.
Number of additional acceleration and deceleration times
required
Number of inputs required
1 at least 1
2...3 at least 2
4...7 at least 3
8...15 4
This function can be assigned to up to four inputs.
For input assignment, observe the notes in chapter 5.6
