Lenze 8203

Configuration
7-4 UOMu_^MVMO
Code IMPORTANTPossible settingsNameCode IMPORTANT
InfoSelectionLenze
Name
[C007
]*
Terminal
configuration
-0- E4 E3 E2 E1
-0- CW/CCWDC brake JOG1/2/3
-1- CW/CCWPAR JOG1/2/3
-2- CW/CCWQSP JOG1/2/3
-3- CW/CCWPAR DC brake JOG1
-4- CW/CCWQSP PAR JOG1
-5- CW/CCWDC brake Trip set JOG1
-6- CW/CCWPAR Trip set JOG1
-7- CW/CCWPAR DC brake Trip set
-8- CW/CCWQSP PAR Trip set
-9- CW/CCWQSP Trip set JOG1
-10- CW/CCWTrip set UP DOWN
-11- CW/CCWDC brake UP DOWN
-12- CW/CCWPAR UP DOWN
-13- CW/CCWQSP UP DOWN
-14- CCW/QSPCW/QSPDC brake JOG1
-15- CCW/QSPCW/QSP PAR JOG1
-16- CCW/QSPCW/QSPJOG1/2/3
-17- CCW/QSPCW/QSP PAR
DC brake
-18- CCW/QSPCW/QSP PAR Trip set
-19- CCW/QSPCW/QSPDC brake Trip set
-20- CCW/QSPCW/QSP Trip set JOG1
-21- CCW/QSPCW/QSP UP DOWN
-22- CCW/QSPCW/QSP UP JOG1
D CW = CW
rotation
D CCW =
CCW
rotation
D DC brake =
DC
injection
brake
D PAR =
Change of
parameter
sets
D JOG = JOG
frequency
D QSP =
Quick stop
D Trip-Set =
External
fault
D UP/DOWN
= Motor
potentiomet
er functions
C008
¿
Function relay
K1
-1- -0- Ready for operation
-1- TRIP fault message
-2- Motor is running
-3- Motor is running / CW rotation
-4- Motor is running / CCW rotation
-5- Field frequency f
d
=0
-6- f
dset
reached
-7- Q
min
reached
-8- I
max
reached
-9- Overtemperature (
J
max
-10 °C)
-10- TRIP or Q
min
or IMP
