Configuration
7-290

SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
C0857 DIS: IN.D1 -2147483648 {1} 2147483647 32-bit phase information
C0858
1
2
3
DIS: OUT.W1
DIS: OUT.W2
DIS: OUT.W3
-199.99 {0.01 %} 199.99 Process output words
Display: 100% = 16384
C0859 DIS: OUT.D1 -2147483648 {1} 2147483647 32-bit phase information
[C1195] CFG: OUT.D2
1000
@ Selection list 3
FIXED0INC
Input phase signal AIF-OUT
C1196 DIS: OUT.D2 -2147483647 {1} 2147483647 Input signal of AIF-OUT
C1197 DIS: IN.D2 Input signal of AIF-IN
AIN
C0034 Mst current 0 0 -10 V ... + 10 V
1 +4mA...+20mA
2 -20 mA ... +20 mA
Selection: Master voltage/master current for
setpoint input
C0400 DIS: OUT -199.99 {0.01 %} 199.99 Output of AIN1
[C0402] CFG: OFFSET
19502
@ Selection list 1
FCODE-26/1
Configuration offset of AIN1
[C0403] CFG: GAIN
19504
@ Selection list 1
FCODE-27/1
Configuration gain of AIN1
C0404
1
2
DIS: OFFSET
DIS: GAIN
-199.99 {0.01 %} 199.99 Input signals of AIN1
C0405 DIS: OUT -199.99 {1 %} 199.99 Output of AIN2
[C0407] CFG: OFFSET
19503
@ Selection list 1
FCODE-26/2
Configuration offset of AIN2
[C0408] CFG: GAIN
19505
@ Selection list 1
FCODE-27/2
Configuration gain of AIN2
C0409
1
2
DIS: OFFSET
DIS: GAIN
-199.99 {0.01 %} 199.99 Input signals of AIN2
AND
[C0820]
1
2
3
CFG: IN1
CFG: IN2
CFG: IN3
1000 FIXED0 @ Selection list 2 Digital inputs AND1
C0821 DIS: C082 Display of C0820
[C0822]
1
2
3
CFG: IN1
CFG: IN2
CFG: IN3
1000 FIXED0 @ Selection list 2 Digital inputs AND2
C0823 DIS: C0822 Display of C0822
[C0824]
1
2
3
CFG: IN1
CFG: IN2
CFG: IN3
1000 FIXED0 @ Selection list 2 Digital inputs AND3
C0825 DIS: C0824 Display of C0824
[C0826]
1
2
3
CFG: IN1
CFG: IN2
CFG: IN3
1000 FIXED0 @ Selection list 2 Digital inputs AND4
C0827 DIS: C0826 Display of C0826
[C0828]
1
2
3
CFG: IN1
CFG: IN2
CFG: IN3
1000 FIXED0 @ Selection list 2 Digital inputs AND5
C0829 DIS: C0828 Display of C0828
[C1175]
1
2
3
CFG: IN1
CFG: IN2
CFG: IN3
1000 FIXED0 @ Selection list 2 Digital inputs AND6
C1176 DIS: C1175 Display of C1175
