Drive Control & Communication
5.4.5 Speed Command Source - Registers #24 & 28
Table 13 lists the Speed Command Source (Register #24 byte D5H or Register #28 DH).
Table 13: Speed Command Source
Setting Source
0 KEYPAD
1 0 – 10VDC
2 4 – 20MA
3 PRESET 1
4 PRESET 2
5 PRESET 3
6 PRESET 4
7 PRESET 5
8 PRESET 6
9 PRESET 7
10 JOG
11 MOP
5.4.6 Auto/Manual Status - Registers #24 & 28
Table 14 lists the Auto/Manual Status (Register #24 byte D5L or Register #28 DL).
Table 14: Auto/Manual Control
Setting Control
0 AUTO
1 MANUAL
