19 RG-SFMOD
Drive Control & Communication
6.2 Parameter List
AC Tech
Register
Number
(hexadecimal
representation)
Parameter
1
Parameter Name Range of Adjustment
Modbus value (decimal value)
Factory Default
51 (33H) 1 Line Voltage 01 - High
02 - Low
01 - High
52 (34H) 2 Carrier Frequency 01 - 4 kHz
02 - 6 kHz
03 - 8 kHz
04 - 10 kHz
02 - 6 kHz
53 (35H) 3 Start Method 01 - Normal
02 - Start on Power-up
03 - Start w/DC Brake
04 - Auto Restart w/DC Brake
05 - Flying Restart 1
06 - Flying Restart 2
07 - Flying Restart 3
01 - Normal
54 (36H) 4 Stop Method 01 - Coast
02 - Coast with DC Brake
03 - Ramp
04 - Ramp with DC Brake
01 - Coast
55 (37H) 5 Speed Source 01 - Keypad
02 - Preset #1
03 - 0-10 VDC
04 - 4-20 mA
01 - Keypad
56 (38H) 6 TB-14 OC Output 01 - None
02 - Run
03 - Fault
04 - Inverse Fault
05 - Fault Lockout
06 - At Set Speed
07 - Above Preset #3
08 - Current Limit
09 - Auto Speed (speed source via terminal strip)
10 - Reverse (rotation direction indication)
01 - None
7 Not Used
58 (3AH) 8 TB-30 Analog Output 01 - None
02 - 0-10 VDC Freq
03 - 2-10 VDC Freq
04 - 0-10 VDC %Load
05 - 2-10 VDC %Load
01 - None
59 (3BH) 9 TB-31 Analog Output 01 - None
02 - 0-10 VDC Load
03 - 2-10 VDC Load
04 - Dynamic Braking
01 - None
1
= Drive's programming parameter number
