RG-SFMOD 20
Drive Control & Communication
AC Tech
Register
Number
(hexadecimal
representation)
Parameter
1
Parameter Name Range of Adjustment
Modbus value (decimal value)
Factory Default
60 (3CH) 10 TB-13A Input 01 - None
02 - 0-10 VDC
03 - 4-20 mA
04 - Preset Speed #1
05 - Run Reverse
06 - Start Reverse
07 - External Fault
08 - Remote Keypad Control
09 - Dynamic Brake Fault
10 - Ramp To Stop
11 - Accel / Decel #2
01 - None
61 (3DH) 11 TB-13B Input 01 - None
02 - 0-10 VDC
03 - 4-20 mA
04 - Preset Speed #2
05 - Decrease Freq (MOP)
06 - Jog Forward
07 - Jog Reverse
08 - Ramp to Stop
01 - None
62 (3EH) 12 TB-13C Input 01 - None
02 - 0-10 VDC
03 - 4-20 mA
04 - Preset Speed #3
05 - Inc Freq (MOP)
06 - External Fault
07 - Remote Keypad Control
08 - Dynamic Brake Fault
09 - Accel / Decel #2
01 - None
63 (3FH) 13 TB-15 OC Output 01 - None
02 - Run
03 - Fault
04 - Inverse Fault
05 - Fault Lockout
06 - At Set Speed
07 - Above Preset #3
08 - Current Limit
09 - Auto Speed (speed source via terminal strip)
10 - Reverse (rotation direction indication)
01 - None
64 (40H) 14 Control 01 - Terminal Strip Only
02 - Remote Keypad Only
03 - Selectable at Terminal
01 - Terminal Strip
1
= Drive's programming parameter number
