Lenze AC Tech SC Series User Manual

21 RG-SFMOD
Drive Control & Communication
AC Tech
Register
Number
(hexadecimal
representation)
Parameter
1
Parameter Name Range of Adjustment
Modbus value (decimal value)
Factory Default
65 (41H) 15 Serial Link 01 - Disable
02 - 9600, 8, N, 2 with Timer
03 - 9600, 8, N, 2, without Timer
04 - 9600, 8, E, 1 with Timer
05 - 9600, 8, E, 1, without Timer
06 - 9600, 8, O, 1 with Timer
07 - 9600, 8, O, 1, without Timer
02 - 9600, N, 2 w/ Timer
66 (42H) 16 Units Editing 01 - Tenths of Units
02 - Whole Units
02 - Whole Units
67 (43H) 17 Rotation 01 - Forward Only
02 - Forward and Reverse
01 - Forward Only
18 Not Used
69 (45H) 19 Acceleration Time 1 – 36000 (0.1 sec – 3600.0 sec) 200 (20.0 sec)
70 (46H) 20 Deceleration Time 1 – 36000 (0.1 sec – 3600.0 sec) 200 (20.0 sec)
71 (47H) 21 DC Brake Time 0 – 36000 (0.0 sec – 3600.0 sec) 0 (0.0 sec)
72 (48H) 22 DC Brake Voltage 0 – 300 (0.0 - 30.0% of nominal voltage) 0 (0.0%)
73 (49H) 23 Minimum Frequency 0 - Maximum Frequency (0.0 - 240.0 Hz) 0 (0.0 Hz)
74 (4AH) 24 Maximum Frequency Minimum Frequency – 2400 (240.0 Hz) 600 (60.0 Hz)
75 (4BH) 25 Current Limit 300 - 1800 (30 – 180%) 1800 (180%)
76 (4CH) 26 Motor Overload 300 - 1000 (30 - 100%) 1000 (100%)
77 (4DH) 27 Base Frequency 250 - 5000 (25.0 - 500.0 Hz) 600 (60.0 Hz)
78 (4EH) 28 Fixed Boost 0 – 300 (0.0 - 30.0%) 10 (1.0%)
79 (4FH) 29 Accel Boost 0 – 200 (0.0 - 20.0%) 0 (0.0%)
80 (50H) 30 Slip Compensation 0 – 50 (0.0 - 5.0%) 0 (0.0%)
81 (51H) 31 Preset Speed #1 0 - Maximum Frequency (0.0 - 240.0 Hz) 0 (0.0 Hz)
82 (52H) 32 Preset Speed #2 0 - Maximum Frequency (0.0 - 240.0 Hz) 0 (0.0 Hz)
83 (53H) 33 Preset Speed #3 0 - Maximum Frequency (0.0 - 240.0 Hz) 0 (0.0 Hz)
84 (54H) 34 Preset Speed #4 0 - Maximum Frequency (0.0 - 240.0 Hz) 0 (0.0 Hz)
85 (55H) 35 Preset Speed #5 /
Skip Frequency #1
0 - Maximum Frequency (0.0 - 240.0 Hz) 0 (0.0 Hz)
86 (56H) 36 Preset Speed #6 /
Skip Frequency #1
0 - Maximum Frequency (0.0 - 240.0 Hz) 0 (0.0 Hz)
87 (57H) 37 Preset Speed #7 /
Skip Frequency #2
0 - Maximum Frequency (0.0 - 240.0 Hz) 0 (0.0 Hz)
88 (58H) 38 Skip Bandwidth 0 - 100 (0.0 - 10.0 Hz) 0 (0.0 Hz)
89 (59H) 39 Speed Scaling 0 – 65000 (0.0 - 6500.0) 0 (0.0)
90 (5AH) 40 Frequency Scaling 30 – 20000 (3.0 - 2000 Hz) 600 (60.0 Hz)
91 (5BH) 41 Load Scaling 100 - 2000 (10 - 200%) 2000 (200%)
1
= Drive's programming parameter number
