RG-SFMOD 22
Drive Control & Communication
AC Tech
Register
Number
(hexadecimal
representation)
Parameter
1
Parameter Name Range of Adjustment
Modbus value (decimal value)
Factory Default
92 (5CH) 42 Accel / Decel #2 1 – 36000 (0.1 sec – 3600.0 sec) 200 (20.0 sec)
93 (5DH) 43 Serial Address 1 - 247 1
94 (5EH) 44 Password 000 - 999 225
45 Not Used
46 Not Used
97 (61H) 47 Clear History 01 - Maintain
02 - Clear
01 - Maintain
98 (62H) 48 Program Selection 01 - User Settings
02 - OEM Settings
03 - Reset OEM
04 - Reset 60
05 - Reset 50
04 - Reset 60
99 (63H) 49 Not Used
Diagnostic – Read Only Parameters! (50# - 60#)
100 (64H) 50 FAULT HISTORY Must Read 4 Words (Read Only) See Note [5]
101 (65H) 51 SOFTWARE VERSION Must Read 1 or 4 Words (Read Only) See Note [6]
102 (66H) 52 BUS VOLTAGE [%] 0-250 (MIN 0% MAX 250%) Read Only
103 (67H) 53 ACTUAL MOTOR
VOLTAGE [%]
0-250 (MIN 0% MAX 250%) Read Only
104 (68H) 54 MOTOR LOAD [%] 0-250 (MIN 0% MAX 250%) Read Only
105 (69H) 55 0-10VDC analog input
[100% = 10VDC]
0-250 (MIN 0% MAX 250%) Read Only
106 (6AH) 56 4-20mA analog input
[100% = 20mA]
0-250 (MIN 0% MAX 250%) Read Only
107 (6BH) 57 DIGITAL I/O SERIAL READ - DIGITAL I/O REPRESENTATION See Note [7]
108 (6CH) 58 DIGITAL I/O SERIAL READ - DIGITAL I/O REPRESENTATION See Note [7]
109 (6DH) 59 ANALOG OUTPUT TB30
[100% = 10VDC]
0-250 (MIN 0% MAX 250%) Read Only
110 (6EH) 60 ANALOG OUTPUT TB31
[100% = 10VDC]
0-250 (MIN 0% MAX 250%) Read Only
1
= Drive's programming parameter number
