Lenze DeviceNet PT E82ZAFVC010 - Page 53

Electrical installation
Voltage supply
3
EDK82ZAFVC010 DE/EN/FR 2.0
53
l
H1E_INST−Merker_hidden ueb−rate
Controller inhibit supply (CINH)
Controller inhibit (CINH) supply via internal voltage source
GND1
V+
20
CHCL SH
28397
GND2
X3.1
X3.2
V-
_
+
E82ZAFD110
Controller inhibit (CINH) supply via external voltage source
GND1
V+
20
CHCL SH
28397
GND2
X3.1
X3.2
V-
_
+
_
+
E82ZAFD112
Min. wiring required for operation
