3 Electrical installation
Voltage supply
EDK82ZAFVC010 DE/EN/FR 2.0
54
l
H1E_INST−Merker_hidden ueb−rate
X3.1/
Designation Function Level
V− Reference potential for external supplyvoltage
CL CAN−LOW CAN data line (LOW)
SH SHIELD Shield
CH CAN−HIGH CAN data line (HIGH)
V+ External supply voltage Please see the notes for external
supply voltage!
X3.2/ Designation Function Level
7 GND1 Reference potential for X3.2/20
39 GND2 Reference potential for controller inhibit (CINH) at X3.2/28
28 CINH Controller inhibit
l Start = HIGH (+12V...+30V)
l Stop = LOW (0 ... +3 V)
20 DC voltage source for internal supply of
controller inhibit (CINH)
+20 V (ref.: GND1)
