Technical data
Rated data
Supply modules
4
l
37
EDS700ACBA EN 5.1
Fuses and cable cross−sections
Operation with external mains choke/mains filter
Type Installation according to EN 60204−1
1)
Installation according to UL
2)
FI
3)
L1, L2, L3 − Laying system L1, L2, L3
B2 C F
[A] [A] [mm
2
] [mm
2
] [mm
2
] [A] [A] [AWG] [mA]
E70ACPSx0304x C40 40 10 6 − 40 40 8 ³ 300
E70ACPSx0604x C63 63 16 10 − − 60 6 ³ 300
1)
The data are recommendations. Other designs/laying systems are possible (e.g. in accordance with VDE 0298−4). The
cable cross−sections apply under the following conditions: use of PVC−insulated copper cables, conductor
temperature < 70 °C, ambient temperature < 45°C, no cable or core bundling, three loaded cores.
2)
Only use UL−approved cables, fuses, and fuse holders.
UL fuse: voltage ³ 500 V, tripping characteristic "J", "T", or "G". The cable cross−sections apply under the following
conditions: conductor temperature < 75 °C, ambient temperature < 45°C.
3)
Universal−current sensitive earth−leakage circuit breaker, short−time delayed, type B
In the case of cable lengths > 50m, depending on the cable type and the switching frequency, the circuit−breaker
may respond.
Circuit breaker
Fuse of gG/gL utilisation category or semiconductor fuses of gRL utilisation category
Fuse
Observe national and regional regulations
