Accessories (overview)
RFI filter/mains filter
11
l
142
EDS700ACBA EN 5.1
11.3 RFI filter/mains filter
Advantages by the use of filters:
ƒ Compliance with EMC requirements
ƒ Reduction of the current load
ƒ Positive effects on the service life of the controllers possible
– Strong reliability
– Reduction of the failure rate
ƒ Operation on 300 mA earth−leakage circuit breakers (type B) for device sizes 1 ... 3
(bis 24 A/11 kW) is enabled. For this purpose, observe the device number and motor
cable lengths according to "Compliance with the EMC category C2 (residential
areas)"(¶ 123)
Mains filters:
Mains filters reduce the conducted interference emission into the mains for compliance
with the requirements acc. to EN 61800−3. Mains filters are a combination of mains choke
and RFI filter in one housing.
Voltage Freq. Current [A] Current [A]
Number of
phases
[V] [Hz] max. +45° C max. +55° C
E94AZMP0084 400/480 50/60 8/8 6/6 3
E94AZMP0294 400/480 50/60 29/29 21.8/21.8 3
E94AZMP0824 400/480 50/60 82/82 61/61 3
Temperature in the control cabinet
RFI filters:
RFI filters are capacitive accessories for compliance with the requirements acc. to
EN 61800−3 for conducted interference emission. RFI filters can be directly connected
upstream of the power supply modules. RFI filters are also called EMC filters.
Voltage Freq. Current [A] Current [A]
Number of
phases
[V] [Hz] max. +45° C max. +55° C
E94AZRP0084 400/480 50/60 8/8 6/6 3
E94AZRP0294 400/480 50/60 29/29 21.8/21.8 3
E94AZRP0824 400/480 50/60 82/82 61/61 3
Temperature in the control cabinet
