Technical data
General electrical data
EDK82MV222 DE/EN/FR 9.0
L
US
dÉåÉê~ä ÉäÉÅíêáÅ~ä Ç~í~
EMC7. Compliance with the requirements acc. to EN 61800-3/A11
Noise emission
Motor mounting Compliance with the limit classes A and B acc.
to EN 55011
Wall mounting
Compliance with the limit class A acc. to
EN 55011 (up to 10 m of shielded motor cable)
Compliance of the limit class B acc. to
EN 55011 (up to 1 m of shielded motor cable)
Enclosure 8.
IP 55
(NEMA 250 type 12)
without protective cap on the AIF interface
IP 65
(NEMA 250 type 4)
with protective cap on the AIF interface
Protective measures against Short circuit, earth fault, overvo ltage, motor stalling, motor
overtemperature (input for PTC thermistor or thermal contact (NC contact),
I
2
t monitoring)
Protective insulation of control
circuits
Safe mains isolation:
Double/reinforced insulation acc. to EN 61800-5-1
Operation on public supply
systems (limitation of
harmonic currents acc. to
EN 61000-3-2)
Total power on the
mains
Compliance with the requirements
1)
0.25 kW ... 0.75 kW with mains choke
>1kW no measures required
NF
qÜÉ ~ÇÇáíáçå~ä ãÉ~ëìêÉë ÇÉëÅêáÄÉÇ çåäó ÉåëìêÉ íÜ~í íÜÉ ÅçåíêçääÉêë ãÉÉí íÜÉ êÉèìáêÉãÉåíë
çÑ íÜÉ bk SNMMMJPJOK qÜÉ ã~ÅÜáåÉLëóëíÉã ã~åìÑ~ÅíìêÉê áë êÉëéçåëáÄäÉ Ñçê íÜÉ Åçãéäá~åÅÉ
ïáíÜ íÜÉ êÉÖìä~íáçåë çÑ íÜÉ ã ~ÅÜáåÉ>
léÉê~íáçå ~í ê~íÉÇ éçïÉê
Typical motor power P
r
[KW] 0.55 0.75 1.5 2.2
8200 motec Type E82MV551_4B E82MV751_4B E82MV152_4B E82MV222_4B
Mains voltage range V
r
[V]
3/PE AC; 320 V - 0 % ... 550 V + 0 %
(45Hz-0%...65Hz+0%)
Data for operation with 3 PE AC 400 V 400 V 400 V 400 V
Rated mains current I
r
[A] 1.8 2.4 3.8 5.5
Output current 8kHz
*
I
r8
[A] 1.8 2.4 3.9 5.6
Max. permissible output
current for 60 s
8kHz
*
I
max8
[A] 2.7 3.6 5.8 8.4
G
fåîÉêíÉê ëïáíÅÜáåÖ ÑêÉèìÉåÅó
