Lenze E82MV551_4B - Linear V;F-Characteristic Control

T
Commissioning
Linear V/f-characteristic control
EDK82MV222 DE/EN/FR 9.0
L
NNO
qÜÉ ÑçääçïáåÖ áåëíêìÅíáçåë ~ééäó íç ÅçåíêçääÉêë ÉèìáééÉÇ ïáíÜ ~ ëí~åÇ~êÇJfLl
ÑìåÅíáçå ãçÇìäÉ ~åÇ ~ íÜêÉÉJéÜ~ëÉ ^` ãçíçê ïÜáÅÜ Ü~ë ÄÉÉå ëÉäÉÅíÉÇ
~ÅÅçêÇáåÖ íç ~ éçïÉêJÄ~ëÉÇ ~ëëáÖåãÉåíK
1. Connect the keypad
2. Ensure that controller inhibit is
active after mains connection
misc001
20 28
X3
}
Terminal X3/28 = LOW
3. Switch on the mains
ON
misc002
4. The keypad is in ”Disp” mode
after approx. 2 s and indicates
the output frequency (C0050)
000
000
abcd e
 mno
p
qr
Hi
Hz
Lo
1
j gfkih PS 
0050
The USEr menu is active
5. Change to the  mode to
configure the basic settings for
your drive
000
000
a bcd e
 mno
p
qr
Hi
Hz
Lo
1
j gfkih PS 
0050
z
y
wx
Blinking on the display:
0050
6. Ada pt the voltage/current range
for the analog setpoint selection
(C0034)
Lenze setting: -0-,
(0 ... 5 V/0 ... 10 V/0 ... 20 mA)
z
y
wx
0
000
abcd e
 mno
p
qr
Hi
Lo
1
j gfkih PS 
0034
SettheDIPswitchonthe
standard I/O to the same
range (see Mounting
Instructions for the
standard I/O)
7. Adapt the terminal configuration
to the wiring (C0007)
Lenze setting: -0-, i. e.
E1: JOG1/3 fixed setpoint
selection
E2: JOG2/3
E3: DCB DC injection brake
E4: CW/CCW rotation
z
y
wx
0
000
a bcd e
 mno
p
qr
Hi
Lo
1
j gfkih PS 
0007
8. Set the minimum output
frequency (C0010)
Lenze setting: 0.00 Hz
MB
xÑz
NMM B
`MMNN
`MMNM
9. Set the maximum output
frequency (C0011)
Lenze setting: 50.00 Hz
