P
Wall mounting
Deliver y package
EDK82MV222 DE/EN/FR 9.0
L
VM
cáÖK P
1a
2a
3
2x
4a
4b
5b
5a
4×
4×
X1
1b
X2
M4×25
M3×16
8200mot003
1a Carrier housing
1b Electronic module
2a Seal
3 Distance and wall plate
4a Wall mounting cover
4b Wall mounting screws
5a Shield sheet
5b Shield sheet screws (for fixing the shielding onto the shield sheet)
X1 Terminal strip mains connection, relay
1
or electronic switching output
2
, brake resistor
X2 Terminal strip motor connection, PTC thermistor or thermal contact (NC contact)
NF áë î~äáÇ Ñçê ÇÉîáÅÉ îÉêëáçå NRN
OF áë î~äáÇ Ñçê ÇÉîáÅÉ îÉêëáçåë NRO ~åÇ NRP
