3 Technical data
3.1 General data and operating conditions
Conformity and approval
Conformity
CE
2006/95/EG Low−Voltage Directive
Approval
UR UL 508C
Power Conversion
Equipment, File No.
E170350
Still in preparation for:
E84DGDVB2224
E84DGDVB3024
C
UR C22.2 No 14
Protection of persons and equipment
Enclosure
EN 60529
IP55, IP65
optional: IP66
in ready−for−use state:
l Close unused bores for
cable glands with
blanking plugs!
l Close unused connectors
with protection covers or
blanking plugs!
NEMA 250 Protection according to
l Type 4
l Type 12
– Not with plug−in
modules or brake
resistor modules.
(Earth) leakage
current
EN 61800−5−1 > 3.5 mA AC,
> 10 mA DC
Observe the regulations and
safety instructions!
Total fault current The following earth−leakage circuit breakers may be
used in TN systems:
Motor mounting
E84DGDVB3714
...
E84DGDVB1524
30 mA, type B
E84DGDVB2224
E84DGDVB3024
300 mA, type B
Wall mounting E84DGDVB3714
...
E84DGDVB3024
300 mA, type B
additional
equipotential bonding
M5 thread with terminal in the WU for connection of
a 16mm@ PE cable
Protective insulation
of control circuits
EN 61800−5−1 Safe isolation from mains by double (reinforced)
insulation
Insulation resistance EN 61800−5−1
Site altitude
0 ... 2000 m Overvoltage category III
2000 ... 4000 m Overvoltage category II
