Lenze E84DGDVB3714 Mounting Instructions

Technical data
Rated data
3

37
EDK84DGDVBxxx4 DE/EN/FR/ES/IT 3.1
3.2 Rated data
Input data
Basis of the data
Mains Voltage Voltage range Frequency range
U
Lrated
[V] U
Lrated
[V] f [Hz]
3/PE AC 400 320 − 0 % ... 440 + 0 % 45 − 0 % ... 65 + 0 %
3/PE AC 480 432 − 0 % ... 528 + 0 % 45 − 0 % ... 65 + 0 %
Voltage Frequency Current [A]
Number
of phases
[V] [Hz] max. +45 °C  max. +55 °C 
E84DGDVB3714 400/480 50/60 1.3/1.1 1.0/0.8 3
E84DGDVB5514 400/480 50/60 1.8/1.5 1.4/1.1 3
E84DGDVB7514 400/480 50/60 2.4/2.0 1.8/1.5 3
E84DGDVB1124 400/480 50/60 3.2/2.7 2.4/2.0 3
E84DGDVB1524 400/480 50/60 3.8/3.1 2.9/2.3 3
E84DGDVB2224 400/480 50/60 5.6/4.6 4.2/3.5 3
E84DGDVB3024 400/480 50/60 7.2/5.9 5.4/4.4 3
 Ambient temperature, switching frequency 4 kHz
Output data
Voltage Frequency Current [A]
Number
of phases
[V] [Hz] max. +45 °C  max. +55 °C 
E84DGDVB3714 400/480 50/60 1.3/1.1 1.0/0.8 3
E84DGDVB5514 400/480 50/60 1.8/1.5 1.4/1.1 3
E84DGDVB7514 400/480 50/60 2.4/2.0 1.8/1.5 3
E84DGDVB1124 400/480 50/60 3.2/2.7 2.4/2.0 3
E84DGDVB1524 400/480 50/60 3.9/3.2 2.9/2.4 3
E84DGDVB2224 400/480 50/60 5.6/4.7 4.2/3.5 3
E84DGDVB3024 400/480 50/60 7.3/6.0 5.4/4.5 3
 Ambient temperature, switching frequency 4 kHz
