Lenze E84DGDVB3714 Mounting Instructions

Settings
Basic settings
6

43
EDK84DGDVBxxx4 DE/EN/FR/ES/IT 3.1
6.1 Basic settings
Possible settings with DIP1
(Lenze setting bold)
DIP1 Switch
Description 1 2 3 4 5 6 7 8
Settings after DIP1, DIP2, P1, P2,
and P3 active
on ( I ) ON
off ( 0 ) OFF
Direction of rotation
left ON
right OFF
Control
quadratic ON
linear OFF
Flying restart circuit
on ( I ) ON
off ( 0 ) OFF
Reserved − OFF OFF OFF
Message type −> on
(only optional with
Communication Unit "+ Safety")
fail −> DO
ready −> NO (relay)
ON
ready −> DO
fail −> NO (relay)
OFF
Possible settings with DIP2
DIP2 Switch
Description 1 2 3 4 5 6 7 8
Rated motor frequency
50 Hz OFF
OFF
60 Hz ON OFF
87 Hz OFF ON
120 Hz ON ON
Mode of the analog input
(only optional with
Communication Unit "+ Safety")
0 ... 10 V OFF OFF
0 ... 20 mA ON OFF
4 ... 20 mA OFF ON
not permissible ON ON
Control mode of technology
application
(cf. selection C00007)
9 (local mode) OFF OFF OFF
10 (terminals 0) ON OFF OFF
12 (terminals 2) OFF ON OFF
14 (terminals 11) ON ON OFF
16 (terminals 16) OFF OFF ON
Reserved ON OFF ON
Reserved OFF ON ON
40 (MCI) ON ON ON
Reserved − OFF
