Settings
Basic settings
6
44
EDK84DGDVBxxx4 DE/EN/FR/ES/IT 3.1
Control modes
DIP2/5−7
Description
(DIx High)
9
(local mode)
The technology application is controlled locally via elements on the controller
and the digital input terminals:
At mains connection the motor starts up automatically if RFR is bridged
or set!
DI1 Setpoint of P2 (speed)
Fixed setpoint 3
DI2 Fixed setpoint 2
DI3 Activate DC injection brake
DI4 Change of direction of rotation (not possible if DIP1/2 = on (set to the
left))
DI5 Release holding brake manually (operating mode after setting C02580)
10
(terminals 0)
The technology application is controlled via the digital input terminals of the
controller:
DI1 Fixed setpoint 1
Fixed setpoint 3
DI2 Fixed setpoint 2
DI3 Activate DC injection brake
DI4 Change of direction of rotation
DI5 Release holding brake manually (operating mode after setting C02580)
12
(terminals 2)
The technology application is controlled via the digital input terminals of the
controller:
DI1 Fixed setpoint 1
Fixed setpoint 3
DI2 Fixed setpoint 2
DI3 Quick stop
DI4 Change of direction of rotation
DI5 Release holding brake manually (operating mode after setting C02580)
14
(terminals 11)
The technology application is controlled via the digital input terminals of the
controller:
DI1 Change of direction of rotation
DI2 Activate DC injection brake
DI3 Motor potentiometer: speed higher
DI4 Motor potentiometer: speed lower
DI5 Release holding brake manually (operating mode after setting C02580)
16
(terminals 16)
The technology application is controlled via the digital input terminals of the
controller:
DI1 Fixed setpoint 1
Fixed setpoint 3
DI2 Fixed setpoint 2
DI3 CW rotation/quick stop
DI4 CCW rotation/quick stop
DI5 Release holding brake manually (operating mode after setting C02580)
40
(MCI)
The technology application is controlled via fieldbus communication.
Depending on the Communication Unit available
To Next Page
