Technical data
General data and operating conditions
3
36
EDK84DGDVBxxx4 DE/EN/FR/ES/IT 3.1
Ambient conditions
Climatic
Storage
IEC/EN 60721−3−1 1K3 (−30 ... +60 °C)
Transport IEC/EN 60721−3−2 2K3 (−30 ... +75 °C)
Operation IEC/EN 60721−3−3 3K3 (−30 ... +55 °C)
Operation at 4 kHz: > +45 °C: Reduce the rated output
current by 2.5 %/°C.
Operation at 8/16 kHz: > +40 °C: Reduce the rated
output current by 2.5 %/°C.
Site altitude < 4000 m amsl
Above 1000 m amsl reduce the rated output current
by 5 %/ 1000 m.
Pollution IEC/EN 61800−5−1 Degree of pollution 2
Mechanical
Vibration resistance (9.81 m/s
2
= 1 g)
Motor mounting
Germanischer
Lloyd
General conditions: Acceleration resistant up to 2 g
IEC/EN 60721−3−3 3M6
Wall mounting
with
E84DZMAWE1
Germanischer
Lloyd
General conditions: Acceleration resistant up to 2 g
IEC/EN 60721−3−3 3M6
Mounting conditions
Mounting place
Motor mounting
Standard
Wall mounting with optional wall
adapter
Ensure convection cooling in
the niches!
Mounting position
Wall mounting Vertical, cooling rips at
the top
Arrangement of several
devices only to the sides, so
that the convection cooling
remains ensured!
Control
Control modes
VFCplus:
l V/f control (linear or square−law)
SLVC:
l Sensorless vector control (speed)
VFCplus eco:
l Energy−efficient V/f control
Switching frequency
4 kHz, 8 kHz, 16 kHz,
