Lenze ECS series User Manual

Commissioning
Setting of the feedback system for position and speed control
Resolver as position and speed encoder
6

114
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
[C0095] Rotor pos adj 0
Activation of rotor position
adjustment for automatic
determination of the rotor
displacement angle.
C0058 displays the determined
rotor displacement angle (offset
angle).
 138
0 Inactive
1 Active
C0414 DIS: ResQual.
Resolver modulation
Quality of the resolver excitation
amplitude set under C0416
(recommendation: 0.5 ... 1.2;
ideal 1.0)
 113
0.00 {0.01} 1,60
[C0416] Resolver adj. 5
Resolver excitation amplitude
 113
0 100 %
1 80 %
2 68 %
3 58 %
4 50 %
5 45 %
6 40 %
7 37 %
[C0417] Resolver cor. 0
Resolver adjustment
 147
0 Ready
1 Start adjustment
2 Loading default values
