System bus (CAN / CAN−AUX) configuration
Diagnostics codes
CAN telegram counter (C0360/2460)
8
178
EDBCSXA064 EN 3.2
8.10.2 CAN telegram counter (C0360/2460)
C0360/2460 counts for all parameter data channel the telegrams which are valid for the
controller. The counters have a width of 16 bits. If the value "65535" is exceeded, counting
restarts with "0".
Counted messages:
C0360/C2460 Meaning
Subcode 1 All sent telegrams
Subcode 2 All received telegrams
Subcode 3 Telegrams sent of CAN1_OUT/CANaux1_OUT
Subcode 4 Telegrams sent of CAN2_OUT/CANaux2_OUT
l Always "0"; channel is not used!
Subcode 5 Telegrams sent of CAN3_OUT/CANaux3_OUT
l Always "0"; channel is not used!
Subcode 6 Telegrams sent of parameter data channel 1
Subcode 7 Telegrams sent of parameter data channel 2
Subcode 8 Telegrams received of CAN1_IN/CANaux1_IN
Subcode 9 Telegrams received of CAN2_IN/CANaux2_IN
l Always "0"; channel is not used!
Subcode 10 Telegrams received of CAN3_IN/CANaux3_IN
l Always "0"; channel is not used!
Subcode 11 Telegrams received of parameter data channel 1
Subcode 12 Telegrams received of parameter data channel 2
