Lenze ECS series User Manual

Appendix
Code table
14

384
EDBCSXA064 EN 3.2
14.5 Code table
How to read the code table
Column Abbreviation Meaning
No.
Cxxxx
Code no. Cxxxx
1 Subcode 1 of Cxxxx
2 Subcode 2 of Cxxxx
Cxxxx Changed input value of the code or subcode is accepted after pressing
.
[Cxxxx] Changed input value of the code or subcode is accepted after pressing
 when the controller is inhibited.
Name LCD display of the keypad XT EMZ9371BC
Lenze/{Appl.}
x Lenze setting:
l Value at the time of delivery or after loading the Lenze setting using
C0002.
{xxx...} Different application initialisation value
l Value at the time of delivery
l After loading the Lenze setting using C0002, the application
initialisation value is overwritten with the Lenze setting.
l The application initialisation values can be restored by loading the
application software with "Global Drive Loader" (GDL).
à The "Important" column contains further information
Selection 1 {%} 99 minimum value {unit}maximum value
IMPORTANT Short code description
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0002 Par load 0
Load parameter set
The Lenze setting can only be
loaded if the controller is
inhibited (CINH).
0 Load Lenze setting Load Lenze setting into the RAM
and activate it.
Only possible if C2108 = 2 (PLC
stopped).
1 Load parameter set 1 Load parameter set 1 into the
RAM and activate it.
Parameter set 1 is loaded
automatically after every mains
connection.
C0003 Par save 0
Non−volatile saving of parameter
set
0 No response
1 Save parameter set
C0004 Op display 56
Selection of XT keypad status
display
1 {Code no.} 9999 The keypad displays the selected
code in the operating level, if no
status messages from C0183 are
active (e. g.: 56 = torque setpoint
(C0056))
