Lenze ECS series User Manual

Commissioning
Operation with motors from other manufacturers
Effecting rotor position adjustment
6

140
EDBCSXA064 EN 3.2
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0058 Rotor diff −90.0
Rotor displacement angle (offset
angle)
Input in case of Lenze motor with
l resolver: −90°
l hiperface absolute value
encoder: 0°
Code value is adapted by the
rotor position adjustment
function (C0095).
Only relevant for the operation
of synchronous motors.
 138
−180.0 {0.1 _} 179.9
[C0095] Rotor pos adj 0
Activation of rotor position
adjustment for automatic
determination of the rotor
displacement angle.
C0058 displays the determined
rotor displacement angle (offset
angle).
 138
0 Inactive
1 Active
