Lenze ECS series User Manual

System bus (CAN / CAN−AUX) configuration
Remote parameterisation (gateway function)
8

181
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0603 MONIT CE5 3
Fault response − gateway
function monitoring (CE5)
"Timeout" when remote
parameter setting (C0370) is
activated via interface X4 (CAN)
 202
 180
0 TRIP
2 Warning
3 Off
C2118 ParWriteChan
.
0
CAN object for L_ParRead and
L_ParWrite
(byComChannel = 10)
 180
0 Unused PDO channel free for
reconfiguration
(CAN1...3_IN/CAN1...3_OUT)
1 Parameter data channel 2
C2470 ParWrite 0
CANaux channel used by
L_ParWrite/L_ParRead
(byComChannel = 11)
 180
0 Unused PDO channel free for
reconfiguration
(CANaux1...3_IN/CANaux1...3_OUT)
1 Parameter data channel 2
C2485 MONIT CE15 3
Fault response − gate function
monitoring (CE15)
"Timeout" when remote
parameterisation (C0370) is
activated via interface X14
(CAN−AUX)
 202
 180
0 TRIP
2 Warning
3 Off
